What the assembly floor covers
Hitech Circuits assembles printed circuit boards from single prototypes to volume production. Four SMT lines and three DIP lines run in the same plant as PCB fabrication, so component sourcing, board assembly, test and box build assembly stay inside one quality system — a fault found at functional test is traced back to the board, the part or the fit without another supplier in the loop.
Assembly processes
- Reflow soldering — the standard surface-mount process: solder paste is printed through a stencil, components are placed and the board is reflowed.
- Wave soldering — molten solder is pumped against the underside of the board to solder through-hole pins in a single pass.
- Selective soldering — a nozzle applies solder to individual through-hole joints, which keeps heat-sensitive neighbouring parts out of a second full thermal cycle.
- Hand insertion and soldering — still the right answer for odd-form parts, heavy connectors and rework.
- Point-to-point wiring — hand-mounted and soldered wiring for repair and legacy assemblies.
Parts can be placed on one or both sides at 4 mil (0.1 mm) pitch, down to 01005 and 0201 chip packages. Every process, and the inspection attached to it, is described on the printed circuit board assembly services page.
Where fabrication, parts and assembly are being sourced from China as one order, the China PCB assembly page explains how the four stages are quoted and traced together, and what paperwork ships with the order.
Engineering review before the first article
The Gerber set, BOM, pick-and-place file and assembly drawing go through DFM, DFA and DFT review: panel and stencil design, component clearance, polarity, test-point access and the placement program. Problems that would stop the line — a missing footprint, a part on stop, a package too close to a connector — are raised before the first board is built. First-article inspection then signs off every feeder, nozzle and vision setting on the run.
Inspection, test and rework
| Stage | What it catches |
|---|---|
| Solder paste inspection (SPI) | Paste volume, bridging and missed deposits before placement |
| Automated optical inspection (AOI) | Placement, polarity and solder defects after reflow |
| X-ray | BGA, micro-BGA, QFN and other joints hidden under the package |
| Ionograph | Ionic contamination left by flux and handling |
| In-circuit (ICT) and flying probe | Opens, shorts, orientation and component values |
| Functional test (FCT) | The board working against the customer test procedure |
Rework is done in-house, including BGA rework and re-balling verified by X-ray, so a board with one bad joint is repaired rather than rebuilt. The full gate list sits on the PCBA testing and quality assurance page.
Turnkey, partial turnkey and consignment
Three commercial models run on the same lines. In a full turnkey order the Gerber data and BOM are all that is needed — parts are sourced, boards fabricated, assembled, tested and packed. In a partial turnkey order the customer supplies the bare boards and selected components. In consignment assembly the customer supplies the components and everything else is handled here. The turnkey electronics assembly service covers the first two as one purchase.
Component supply is run by the components sourcing team, buying against the whole BOM and holding moisture-sensitive parts in temperature- and humidity-controlled storage; where a part is obsolete or on a long lead, a substitute is proposed before the schedule slips.
Getting a quotation
