Panelisation: V-Score, Tabs and Rails

Why panelise at all

Automated assembly works better with larger formats. A small board on its own is hard to clamp, print and place; several of them on a panel give the machine something to hold, and one print/place/reflow pass serves many boards.

The price of that convenience is a set of rules about how the panel is built and how it comes apart.

V-score

A V-shaped blade cuts a groove about one third of the way through the board from each side, leaving a web in the middle. The panel stays rigid enough to run through assembly, then breaks along the line.

  • Best for: rectangular boards, no edge components, straight break lines.
  • Clearance: at least 1.27 mm from any component to the score, 3.2 mm for MLCCs.
  • Thickness: the plant range is 0.6–3.2 mm, with angle tolerance ±0.5°.
  • Edge: visibly rough, with a slight bevel; fine where the edge is not seen or handled.
  • Cost: the cheapest option, and the least material wasted.

Tab routing

The boards are routed out and held by small tabs, often perforated with three or five holes so they snap cleanly.

  • Best for: unusual outlines, edge-hanging connectors, boards that need a smooth routed edge.
  • Clearance: at least 3.2 mm from components and traces to the tab, 6.4 mm for MLCCs.
  • Tab pitch: roughly every 50–75 mm for five-hole tabs, 38 mm for three-hole tabs.
  • Edge: smooth from the router, with small nubs that sand off.
  • Cost: more router time and more material lost to the routing channel.

Rails and what goes on them

A rail is the border of the panel that is not part of any board. It carries:

  • Fiducials — at least three, so the machine can align even if one is missed.
  • Tooling holes — for fixture pins and for the printer.
  • Test coupons — impedance and cross-section structures, placed where they represent the board.
  • Barcode or label area — for traceability.
  • Jump scoring — a partly scored breakaway strip along the leading and trailing edge, which keeps a long panel flat through wave solder.

Breakout

The panel is only as good as the way it is separated. Hand-breaking a tab puts bending stress through the nearest joints; a proper depaneliser shears along the line instead. V-scored panels need a cutter; tabbed panels can be snapped by hand, but on a thick board a router or hook blade is safer.

Whatever the method, the components near the break line take the stress. That is why the clearance rules exist, and why they are checked in DFM rather than at the bench.

What to send

The board outline and array preference, the panel size limits, any edge components, the depanelisation method, and the fiducial and tooling-hole positions if the assembly fixture is already fixed. Panels go up to 580 × 1900 mm; the assembly constraints are on the PCBA manufacturing page, and the fabrication sequence in the process note.

Technical Specifications

Maximum panel
580 × 1900 mm
V-score depth
about one third of the thickness from each side
V-cut thickness range
0.6–3.2 mm · angle tolerance ±0.5°
Component to score line
at least 1.27 mm (0.05″)
MLCC to score line
at least 3.2 mm (1/8″)

Frequently Asked Questions

  • V-score or tab routing?

    V-score suits rectangular boards with no parts near the edge: it is cheaper, wastes less material and needs only a pizza-cutter style depaneliser, at the cost of rougher edges. Tab routing suits odd shapes and boards with edge-hanging components, and gives cleaner edges, but takes more router time. The two are often combined on one panel, edge by edge.

  • Why keep ceramic capacitors away from the score line?

    Depanelisation bends the board along the score, and a multilayer ceramic capacitor is brittle. The industry rule is at least 1/8 inch between an MLCC and the score line, and at least 0.05 inch between any component and the V-groove. A part placed closer can crack internally and pass test, then fail in the field.

  • What belongs on the rail?

    Fiducials for the placement machine, tooling holes for the fixture, a barcode or label area, and test coupons for impedance and cross-section. Jump-scored breakaway strips on the leading and trailing edges keep a long panel from sagging through wave solder. The rail is the part of the panel that carries the process, so it should not be treated as waste.
